1 · Product photos
Watermarked studio view. Click image to enlarge. Use thumbs for product / drawing roles.
Product
RD24-B
RD24-B waterproof male socket 3+PE-4pin
Browse Civil Circular Aviation Connectors →Engineering reply within 24 hours. Drawing confirmation recommended before release. Need CAD, plating, photos, or reports — include target OEM PN in the RFQ.
2 · Product data drawings
Engineering drawings ship with the 24-hour RFQ pack when not published.
No separate drawing pack online for this PN yet.
Request dimensions / pinout for RD24-B →3 · Shipping & packaging
All packing and shipment are executed by 86connector Shenzhen warehouse (Shenzhen warehouse — unified dispatch). Shenyang plant is manufacturing capability background only when listed. Batch photos available on request with order confirmation.
| Lead time | 2–4 weeks typical (stock items faster) |
| MOQ | Standard pack — RFQ for small lots |
| Packaging | Export carton + bag/tray |
| Fulfillment | 86connector Shenzhen warehouse — unified export dispatch |
4 · Specifications & reports
Engineering parameters, downloadable documents, and quality reports. Missing files are fulfilled via RFQ within 24 hours — no fake downloads.
Technical specifications
Identity
| Part Number | RD24-B |
| Series | RD24 Series |
| Fulfillment | 86connector Shenzhen warehouse — unified export dispatch |
Mechanical
| Product Type | Receptacle |
| Termination | Cable |
Electrical
| Contacts | 4 contacts |
| Gender | Male |
Other
| Lead Time | 2–4 weeks typical (stock items faster) |
| MOQ | Standard pack — RFQ for small lots |
| Packaging | Export carton + bag/tray |
Documents
Datasheets and drawings ship with the engineering pack for RD24-B. Request below — typical reply within 24 hours.
Quality & test reports
Lot/type test and compliance files. Unpublished items return via RFQ.
Same series. Confirm insert / gender against your drawing before order.
